WORKLIGHT 2" x 2" SPOT PATTERN #93210
In stock — ready to ship

WORKLIGHT 2" x 2" SPOT PATTERN #93210

SKU #93210

$115.09

White emitting spot light with12-24Vdc operation
Die cast zinc housing
Impact resistant polycarbonate front shield
IP68 rating
Tested to US MIL810-STD standard
CE and Rohs certified
Waterproof deutsch connector
Comes with wiring pigtail and wiring harness with switch
Comes with mounting bracket and stainless steel hardware
Spot beam of approximately 10-15 degree (total) spread

SKU
#93210
Availability
In Stock
View cart →

FEATURES

  • 12-24Vdc operation
  • Die cast zinc housing
  • Impact resistant polycarbonate front shield
  • IP68 rating
  • Tested to US MIL810-STD standard
  • CE & Rohs certified
  • Waterproof Deutsch connector
  • Comes with wiring pigtail, and wiring harness with switch
  • Comes with mounting bracket and stainless steel hardware
  • Available in flood, and driving beam patterns
  • These items are final sale and cannot be returned.
Part #VdcLumensAmps#LEDsBeam Pattern
93210 12-24 1430 0.8 4 Spot
93220 12-24 1736 1.2 8 Spot
93230 12-24 2604 1.8 12 Spot
93250 12-24 8680 6.0 40 Spot
93260 12-24 13020 9.0 60 Spot
93270 12-24 17360 12.0 80 Spot
93280 12-24 21700 15.0 100 Spot

Downloads

Dimensions & diagrams

Diagram
